Model: LFZP-008A
Application: Suitable for weighing and filling all kinds of fragile and breakable materials, such as soap capsules, laundry capsules, laundry gel, laundry pod, laundry tablets, etc.
Model: LFZP-008A
Application: Suitable for weighing and filling all kinds of fragile and breakable materials, such as soap capsules, laundry capsules, laundry gel, laundry pod, laundry tablets, etc.
Application
Application:
Suitable for weighing and filling all kinds of fragile and breakable materials, such as soap capsules, laundry capsules, laundry gel, laundry pod, laundry tablets, etc.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packing Exambers:
Features:
It adopts a deceleration lifting motor, an automatic feeding control system when the material is missing, and the bucket type.
The lifting mechanism is completely closed, non-polluting, with no leakage, feeding, weighing, filling, and full automation control.
Equipped with a domestic well-known ultra-miniature combination, the filling speed is fast and the precision is high.
Multi-language touch screen human-computer interaction system, visual operation, can also record the total number of cans, pass rate and single can error of each batch.
Additional installation of rejecting device, materials that do not meet the required weight, will be diverted to another outlet, greatly improving the qualification rate of filling and avoiding waste.
Specifcations:
Model | LFZP-008A |
Speed | 15-30pcs/min |
Bottle diameter | Φ30mm-Φ135mm (customizable) |
Bottle height | 40mm-200mm (customizable) |
Control system | PLC |
Power supply | 220V、50Hz |
Air consumption | 0 |
Dimension | 2000mm*900mm*1400mm(L*W*H) |
Equipment Material | 304 |
Weight | 200KG |
Description of the main packaging process | Bottle feeding-weighing-unloading-bottle out |
Video:
