Application
Application:
It is suitable for all kinds of premade bags, such as zipper pouches, pillow bags, 3-side, 4-side and 8-side quad seal bags (box pouch), kraft bags and spout bags and so on.
It is widely used For lots of applications such as coffee, frozen foods, cookies, cereals, nuts, flowers, candy, etc.
Kindly Reminder:
We have an experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packing Exambers:
Features:
Easy to operate, adopt advanced PLC from Japan Mitsubishi, mate with touch screen and electric control system, the man-machine interface is friendly.
Automatic checking: no pouch or pouch open error, no fill, no seal. the bag can be used again, avoid wasting packing materials and raw materials.
Safety device: Machine stop at the abnormal air pressure, heater disconnection alarm.
The width of the bags could be adjusted by an electrical motor.
It matches the glass safety door. The machine will stop working when you open the door. So that it could protect the safety of operators. At the same time, it could prevent dust.
The packing materials loss low and this machine is used the preformed bag, the bag pattern is perfect and has a high quality of the sealing part, this improved the product specification.
With different feeders changed to pack solid, liquid, thick liquid, powder and so on.
The packing bag suits in extensive range, suit for multi-layer compound, monolayer PE, PP and so on Preformed bag made by film and paper.
Specifications:
Model: LD-MD300
Premade Pouch Type: 3 side sealing sachet/ stand up bag(doypack bag) / zipper bag /spout bag
Premade Pouch Size: W 90-300mm X L 100-300mm
Packing Speed: 6-15 bags/min
Power Supply: 220V / 50HZ / 60Hz, single phase / 20 A;
Air consumption: 0.5m3 / min 0.65Mpa;
Machine dimension: L: 1750mm * W: 510mm * H: 1300mm
Mechanical building: SS304 3mm thick chassis/bearing/connecting parts;
Electrical configuration: PLC Mitsubishi from Japan, PID temperature control Omron, 5.7-inch color touch screen; Delta from Taiwan
Pneumatic configuration: Pneumatic component AirTAC from Taiwan, vacuum generator, PIAB from Sweden
Optional Devices:
Auto Zipper open device
SMC Pneumatic Parts
Product Settler
Gas flush and vacuum function
Take Away Conveyors
Filling devices
Ribbon Stamp Printer
