Application
Application:
Suitable for packing biscuits, cake, bread, cookies, meat muffin, flaky pastry, moon cake, several sausages in a bag, noodles, beef jerky, egg roll, etc.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packing Exambers:
Features:
Compact machine structure with smaller footprint area.
Carbon steel or stainless steel machine frame with a nice appearance.
Optimized component design realizing fast and stable packing speed.
Servo control system with higher accuracy and flexibility mechanical motion.
Different optional configurations and functions meet different specific requirements.
Specifications:
| Model | LP-250B | LP-350B | LP-450B | LP-600B |
| Film width | Max250mm | Max350mm | Max450mm | Max600mm |
| Bag length | 65-190mm or120-280mm | 65-190mm or120-280mm | 150-450mm | 160-500mm |
| Bag width | 30-110mm | 50-160mm | 50-180mm | 100-280mm |
| Product height | Max.40mm | Max.40mm | Max.75mm | Max.110mm |
| Film roll diameter | Max.320mm |
| Packaging rate | 40-230 bags/min | 40-180bags/min | 30-150Bags/min | 20-150 bags/min |
| Power | 220V,50/60Hz,2.4kw | 220V,50/60Hz,2.6kw | 220V,50/60Hz,2.8kw | 220V,50/60Hz,2.8kw |
| Machine size | （L）3770*（W）720*（H）1420mm | （L）4030*（W）770*（H）1420mm | (L)4030*(W)820*(H)1420mm | (L)4030*(W)970*(H)1500mm |
| Machine quality | About 500kg | About 580kg | About650kg | About680kg |
| Remarks | optional air filling device）/optional angle folding） |
| Film material） | OPP/ PE/ PVC/ OPP/ CPP/ PT/ PE/ KOP/ CPP/ Aluminum Coating Film/ Aluminum Film |
Optional Devices:
Date Coder
Touchable Screen
Automatic Punching Device
Alternative sealing patterns and notch
Auto labeling device
Deoxidizer chute device
Gas flushing device
