Application
Application:
Widely used in packaging of daily necessities, shampoos, gum boxes, books, disposable tableware, carton boxes, etc.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packing Exambers:
Features:
The preset number of products can be memorized to maintain 100 product specifications. Enter the product number during production to enter the production state most quickly and save debugging workload
Automatic temperature control, PLC control, three-servo control, can quickly change the packaging, high-altitude electric eye automatic tracking, no need to manually adjust after setting, the sealing and cutting size and position are accurate, and the sealing is firm and beautiful
The sealing and cutting knife is treated with special alloy material sprayed with Teflon, and it does not stick to the film
The drum outside the high temperature resistant silicone tube can rotate freely, stainless steel heating tube, internal three-layer heat insulation, high-power circulating fan, two-way hot circulating air to make the heat even and constant temperature.
Specifications:
| Model | LP-590 (Flow packing machine) |
| Packing speed (depending on product specifications) packs/min | 5-120 5-120 /minute |
| Product dimension (mm) | L:60-280 /W:60-200 H:30-100 |
| Voltage (V) | 220/380V/50HZ |
| Total Power（KW） | About 5.5KW |
| Machine size (mm) | 2700*1000*1680mm |
| Feeder (mm) | 3050*500*900mm |
| Weight | 800KG |
| Model | LP-240 (Shrink wrapper) |
| Voltage | 380V/50HZ-60HZ |
| Total Power | About 15KW |
| Packing speed | 220/380V/50H |
| Machine size | 2400*710*1400mm |
| Weigh | 400kg |
| Application film | POF PE PVC PP |
Optional Devices:
Belt material conveyor
End sealing drag chain
Auxiliary material feeding device
Material cut prevent device
Perforating device
Date printer
Labeling machine
Thermal transfer code printer
Cutting stop
